High Strength

These screws have high strength. They include screws made of particularly strong titanium, stainless steel, and plastic.
Using high-strength screws allows for smaller screw sizes while maintaining fastening force, contributing to more compact and lightweight equipment.
High-Strength_1en High-Strength_2en

Part Name	Hex Socket Head Cap Screws with Ventilation Hole - High Intensity Stainless Steel	Hex Socket Head Cap Screws - High Intensity Stainless Steel	Hex Socket Head Cap Screws - High Intensity S.S.	Hex Socket Head Cap Screws - High Intensity S.S.	Washer Integrated Hex Socket Head Cap Screws - High Strength Stainless Steel	Washer Integrated Hex Socket Head Cap Screws with Ventilation Hole - High Strength Stainless Steel	Socket Head Cap Captive Screws - High Intensity Stainless Steel	Hex Socket Head Cap Screws - High Intensity Titanium Alloy	Socket Head Cap Captive Screws - High Intensity Titanium
Part Number	SVSLG	SNSLG	SNSX-88	SNSX-109	SNSQLG	SVSQLG	SSC-SNSLG	SNSTG	SSC-SNSTG
Feature	High Strength(Equivalent to Strength Class 10.8)	High Strength (Tensile Strength Ranking 10.8 Equivalent) Heat Resistance Corrosion Resistance Nonmagnetic	High Strength HeatResistance Corrosion Resistance Nonmagnetic	High Strength HeatResistance Corrosion Resistance Nonmagnetic	High Strength (Tensile Strength Ranking 10.8 Equivalent) Heat Resistance Corrosion Resistance Nonmagnetic Integrated Washers I=3	High Strength (Tensile Strength Ranking 10.8 Equivalent) Integrated Washers I=3	High Strength (Strength Class 10.8 Equivalent) Heat Resistance Corrosion Resistance Non-magnetic Captive/Loss Prevention	High Strength Lightweight Nonmagnetic Corrosion Resistance	High Strength Lightweight Non-magnetic Corrosion Resistance Captive/Loss Prevention
Material	SUS316L	SUS316L	SUS316L HiMo	SUS316L HiMo	SUS316L	SUS316L	SUS316L	Grade 5 Titanium	Grade 5 Titanium
Surface Treatment	-	-	-	-	-	-	-	Special Chemical Polishing	-
Thread Size	M3 ～ M6	M3 ～ M6	M3 ～ M8	M6 ～ M12	M3 ～ M6	M3 ～ M6	M3 ～ M6	M2 ～ M10	M3 ～ M8
Operating Temperature (℃)	-	-	-	-	-	-	-	-	-
CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD
Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications
List	SVSLG-M3 SVSLG-M4 SVSLG-M5 SVSLG-M6	SNSLG-M3 SNSLG-M4 SNSLG-M5 SNSLG-M6	SNSX-M3-88 SNSX-M4-88 SNSX-M5-88 SNSX-M6-88 SNSX-M8-88	SNSX-M10-109 SNSX-M12-109 SNSX-M6-109 SNSX-M8-109	SNSQLG-M3 SNSQLG-M4 SNSQLG-M5 SNSQLG-M6	SVSQLG-M3 SVSQLG-M4 SVSQLG-M5 SVSQLG-M6	SSC-SNSLG-M3 SSC-SNSLG-M4 SSC-SNSLG-M5 SSC-SNSLG-M6	SNSTG-M10 SNSTG-M2 SNSTG-M2.5 SNSTG-M3 SNSTG-M4 SNSTG-M5 SNSTG-M6 SNSTG-M8	SSC-SNSTG-M3 SSC-SNSTG-M4 SSC-SNSTG-M5 SSC-SNSTG-M6 SSC-SNSTG-M8

Part Name	Cross Recessed Pan Head Machine Screws - High Intensity Titanium Alloy	Cross Recessed Flat Head Machine Screws - High Intensity Titanium Alloy	Hex Socket Head Cap Screws - Electroless Nickel Plating	Socket Head Cap Screws	Socket Head Cap Screws / Fine Thread	Socket Head Cap Captive Screws - Electroless Nickel Plating	Plastic Screws - Hex Socket Head Cap Screws - PEEK GF30	Plastic Screw - Cross Recessed Pan Head Machine Screws - RENY	Plastic Screw - Cross Recessed Pan Head Machine Screw - RENY - Inch Thread
Part Number	SNPTG	SNFTG	SNS-EL	SNS-J	SNS-M-P	SSC-SNS-EL	SPEG-C	SPA-P	SPA-P(INCH)
Feature	High Strength Lightweight Nonmagnetic Corrosion Resistance	High Strength Lightweight Nonmagnetic Corrosion Resistance	High Strength	Hex Socket Head Cap Screws Conforming to JIS B 1176	Positioning Loosening Countermeasures Conforming to JIS B 1176	High Strength Captive/Loss Prevention	Chemical Resistance Heat Resistance High Strength	High Strength High Specific Strength	High Strength High Specific Strength
Material	β Titanium	β Titanium	Steel	Steel	Steel	Steel	PEEK GF30	RENY	RENY
Surface Treatment	Special Chemical Polishing	Special Chemical Polishing	Electroless nickel plating	Ferrosoferric Oxide Film (Black)	Ferrosoferric Oxide Film (Black)	Electroless nickel plating	-	-	-
Thread Size	M3 ～ M5	M3 ～ M5	M3 ～ M10	M3 ～ M16	M6 ～ M16	M3 ～ M8	M3 ～ M5	M1.7 ～ M8	No.4-40UNC
Operating Temperature (℃)	-	-	-	-	-	-	-	-	-
CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD
Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications
List	SNPTG-M3 SNPTG-M4 SNPTG-M5	SNFTG-M3 SNFTG-M4 SNFTG-M5	SNS-M10-EL SNS-M3-EL SNS-M4-EL SNS-M5-EL SNS-M6-EL SNS-M8-EL	SNS-M10 SNS-M12 SNS-M16 SNS-M3 SNS-M4 SNS-M5 SNS-M6 SNS-M8	SNS-M10-P1.25 SNS-M12-P1.25 SNS-M16-P1.5 SNS-M6-P0.75 SNS-M8-P1	SSC-SNS-M3-EL SSC-SNS-M4-EL SSC-SNS-M5-EL SSC-SNS-M6-EL SSC-SNS-M8-EL	SPEG-M3-C SPEG-M4-C SPEG-M5-C	SPA-M1.7-P SPA-M2.6-P SPA-M2-P SPA-M3-P SPA-M4-P SPA-M5-P SPA-M6-P SPA-M8-P	SPA-#4-40-P

Part Name	Plastic Screws - Cross Recessed Flat Head Machine Screws - RENY	Plastic Screw - Hex Head Screws - RENY	Plastic Screw - Socket Head Cap Screws - RENY	Plastic screw - Hex Socket Low Head Bolt - RENY	Plastic Screws - Hexalobular Socket Head Cap Screw with Low Profile - RENY	Plastic Screws - Hexalobular Socket Head Cap Screw with Ultra Low Head - RENY	Plastic screw - Cross Recessed Pan Head Machine Screws for Precision Instruments - RENY	Plastic Screw - Cross Recessed Flat Head Machine Screws for Precision Instruments - RENY	Plastic Screws - Hex Posts - RENY
Part Number	SPA-F	SPA-H	SPA-C	SPA-LC	SPA-LH	SPA-SH	SPA-MC	SPA-MF	SPA-HA
Feature	High Strength High Specific Strength	High Strength High Specific Strength	High Strength High Specific Strength	High Strength High Specific Strength Low Profile Space Saving	High Strength High Specific Strength Low Profile Space Saving	High Strength High Specific Strength Low Profile Space Saving	High Strength High Specific Strength For Precision Instruments	High Strength High Specific Strength For precision equipment	RENY High Strength High Specific Strength
Material	RENY	RENY	RENY	RENY	RENY	RENY	RENY	RENY	RENY
Surface Treatment	-	-	-	-	-	-	-	-	-
Thread Size	M2 ～ M8	M5 ～ M16	M3 ～ M12	M3 ～ M6	M3 ～ M6	M3 ～ M6	M1.2 ～ M1.6	M1.2 ～ M1.6	M3 ～ M4
Operating Temperature (℃)	-	-	-	-	-	-	-	-	-
CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD	CAD
Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications	Specifications
List	SPA-M2.6-F SPA-M2-F SPA-M3-F SPA-M4-F SPA-M5-F SPA-M6-F SPA-M8-F	SPA-M10-H SPA-M12-H SPA-M16-H SPA-M5-H SPA-M6-H SPA-M8-H	SPA-M10-C SPA-M12-C SPA-M3-C SPA-M4-C SPA-M5-C SPA-M6-C SPA-M8-C	SPA-M3-LC SPA-M4-LC SPA-M5-LC SPA-M6-LC	SPA-M3-LH SPA-M4-LH SPA-M5-LH SPA-M6-LH	SPA-M3-SH SPA-M4-SH SPA-M5-SH SPA-M6-SH	SPA-M1.2-MC SPA-M1.4-MC SPA-M1.6-MC	SPA-M1.2-MF SPA-M1.4-MF SPA-M1.6-MF	SPA-M3-HA SPA-M4-HA

Part Name	Plastic Screws - Threaded Rods - RENY	Plastic Screw - Hex Nuts / Washers - RENY	Plastic Screw - Hex Nuts / Washers - RENY
Part Number	SPA-Z	SPA-N	SPA-W
Feature	High Strength High Specific Strength	High Strength	High Strength
Material	RENY	RENY	RENY
Surface Treatment	-	-	-
Thread Size	M6 ～ M16	M2 ～ M16	M3 ～ M16
Operating Temperature (℃)	-	-	-
CAD	CAD	CAD	CAD
Specifications	Specifications	Specifications	Specifications
List	SPA-M10-Z SPA-M12-Z SPA-M16-Z SPA-M6-Z SPA-M8-Z	SPA-M10-N SPA-M12-N SPA-M16-N SPA-M2.6-N SPA-M2-N SPA-M3-N SPA-M4-N SPA-M5-N SPA-M6-N SPA-M8-N	SPA-10-W SPA-12-W SPA-16-W SPA-3-W SPA-4-W SPA-5-W SPA-6-W SPA-8-W

Latest

Galling and Seizing

This is a phenomenon that occurs while tightening, where the surface of the screw thread melts or welds due to frictional heat and the screw stops moving. To resolve galling, NBK's special surface treatment screws, such as those with fluorine coating, are recommended.

What are Hex Nuts?

Here we offer a clear introduction to hex nuts.

What makes our custom screws special

The machine parts manufacturer Nabeya Bi-tech Kaisha (NBK) at e-nedzi.com manufactures special screws to the customer's specifications, such as tip machining and surface treatment. Special material screws, resin screws and loosening prevention are also available.

Vol. 13 Explaining the Rust Source "Galvanic Corrosion"

Have you ever been surprised by rust suddenly appearing on rust-resistant aluminum?
If this happens, the reduced strength resulting from the corrosion brings fears of possible damage.
This phenomenon is known as "galvanic corrosion". Today, I will explain this principle and how it can be handled.
