What is a Swivel Mount?

➡To [Descriptipn of Mechanical Components for Engineers]

What is a Swivel Mount?

A swivel mount is a unit designed to rotate and secure control panels, such as those found on machine tools.
It allows you to freely adjust the angle of the control panel for easy viewing, thereby enhancing work efficiency.
Additionally, it features black paint, giving it a sleek appearance that blends well with the equipment.

The installation method can be selected from either a pillar type or a hanging type.

Pillar Type
Hanging Type
Rotation can be easily locked at any angle with the attached lever, allowing for tool-less operation.
Furthermore, wiring for the control panel can be routed through the central hole of the swivel unit.

Lineup List



DKSF

DKSW

 Mounting Type

Pillar Type

Hanging Type

  		Pillar Type

 Size

 Outer Diameter

  φ115  φ130  φ120

 Inner Diameter

  φ45  φ60  φ45

 Mounting Pitch

  φ95
  φ110  φ100

 Allowable Moment

  200N･m  315N･m  125N･m

 Weight

  2,580g  3,130g  3,200g

 Rotation Angle

   45°,75°,90°,120°,150°,180°,
240°,270°,315°,360°

 60°,90°,120°,180°,
240°,270°,360°

 Rotation Mechanisms

 Rolling Bearings
(Low friction of sliding parts and light operating torque)

 Sliding Bearings
(Providing a moderate operating sensation)

Fixing Method

 Can be installed from the equipment side or from the Swivel Mount side
Easy to install even in thin and difficult-to-install locations.


 Installation of control panel
